AIR TORQUE DR00030U AL PNEUMATIC ACTUATOR

Rs. 0.00
Rs. 0.00
Sale Sold out
Model No
Condition
Reference No
  • Brand

    AIR TORQUE
AIR TORQUE DR00030U AL PNEUMATIC ACTUATOR
AIR TORQUE
MODEL : DR00030U AL
PNEUMATIC ACTUATOR
EN ISO 5211 : F05F07-Y-H-11x14
MAX.PRESSURE : 8 BAR
TORQUE At : 5,5 BAR MAX.Nm : 32,2
TEMP.: -40'C TO +80'C
ACCESSORY CONNECTION : AA1
AIR CONNECTION : G 1/8"
ATEX 2014/34/EU II 2GD c T95'C
T.F.: ATX 09AT
IEC 61508 : SIL 3 CAPABLE
SERIAL.NO : 18060274
ROTECH
MODEL : ACR1AREAAZZM252M20AL
ALB-MODEL CROUZET : 83.139.1
ALUMINUM HOUSING : 160x82x60
WITH M25x1.5 + M20x1.5 SW.Ex e
SER.NR : 197489 039
PARKER LUCIFER
CAT.NO : 34135
10 BAR ORIF.: 7mm
PARKER LUCIFER
P/N : 495905C2
SOLENOID COIL 24VDC IP66/67
WEIGHT : 3.550.Kg
MADE IN ITALY
CONDITION : USED 2 PCS
REF.NO : 191495
